The fan can do customized 3V,5V,12V,15V,20V,24V,48V.
The 5V DC radiator fan also has the advantages of small size, light weight, high speed and low noise, so it is more compact in structure and easy to carry and install. The speed of a DC fan can be achieved by adjusting the voltage or using a frequency converter, while the speed of an AC fan is usually fixed. These features make it possible for DC fans to be used for personal use as well as when there is no power supply, while AC fans must be connected to AC power to work properly.
Our factory
Fan drawing
Datasheet
|
Size |
Model |
Rated Voltage |
Startup Voltage |
Current Amp (A) |
Speed |
Air flow |
Static Pressure |
Noise Level |
Weight |
|
50*50*12mm |
XYJ05B5010M |
5 |
3.5 |
0.14 |
4500 |
10.17 |
3.11 |
26.3 |
20.00 |
|
XYJ05B5010L |
5 |
3.5 |
0.06 |
3000 |
6.36 |
1.36 |
17.1 |
20.00 |
|
|
XYJ12B5010H |
12 |
6 |
0.20 |
6500 |
14.63 |
6.07 |
36.8 |
20.00 |
|
|
XYJ12B5010M |
12 |
6 |
0.06 |
4500 |
10.17 |
3.11 |
26.3 |
20.00 |
|
|
XYJ12B5010L |
12 |
6 |
0.04 |
3000 |
6.36 |
1.36 |
17.1 |
20.00 |
|
|
XYJ24B5010H |
24 |
12 |
0.03 |
4500 |
10.17 |
3.11 |
26.3 |
20.00 |
|
|
XYJ24B5010M |
24 |
12 |
0.10 |
6500 |
14.63 |
6.07 |
36.8 |
20.00 |
Spare part-Fan grill
Rated fan
Certificate
Packing details:
500PCS to a carton
Carton size:30.5*29*34.5CM
Total about 12KG/CTN
Delivery
1.Sample:by air or express;
2.Mass production:by sea or train.
